PRODUCT INTRODUCTION
PRODUCT SPECIFICATION
PRODUCT NAMEHIGH POWER CLASS D CAR AUDIO AMPLIFIER
MODEL NO.A1
TYPE (FREQUENCY)WIDE RANGE
CHANNEL1
OPERATING VOLTAGE 11-16V
OUTPUT POWER 730W*1CH (@14.4V/1 OHM)
OUTPUT POWER 380W*1CH (@14.4V/2 OHM)
OUTPUT POWER 230W*1CH (@14.4V/4 OHM)
INPUT SENSITIVITY0.2-6V
SNR≥ 95 dB
FREQUENCY RESPONSE15 - 300Hz
LOW PASS FILTER35-270Hz
SUBSONIC FILTER10-50Hz
HIGH PASS FILTER-
PHASE REGULATION0 - 180°
MIN. LOAD ON SINGLE CHANNEL1 OHM
MIN. LOAD IN BRIDGE MODEUNBRIDGABLE
MIN. LOAD IN LINK MODEUNLINKABLE
SIZE (L*W*H)31*18*6.5
WEIGHT3.5KGS
PRODUCT DETAILS
IT SOUNDS GREAT ！
